- Capacity up to 750 m3/Hr
- Head up to 90 meters
- Maximum temperature up to 300oC
- Operating frequency of 50Hz & 60Hz
- Manufactured as per ISO 2858, ISO 5199 & DIN 24256.
- Maximum submergence length of up to 8 meters
- Intermediate bearing bush at every 1.0 meter shaft length.
- Glass/Bronze/Carbon filed Teflon bush can be provided.
- Silicone Carbide bush/Special slurry application bush can be provided for slurry application.
- Internal/External flushing provided.
- Mechanical seal arrangement can be provided if required.
- Completely steam jacketed pump for molten Sulphur application (140oC - 150oC)
- Vapor proof Construction of pump also available.
- Rubber lining option available
Available in CF8, CF8M, Cf3, CF3M, A-20, R-55, H-B, H-C, CZ100, CA6NM, CD4MCu and other special Alloys.
Ideal for:
- Chemical, solvent & acid handling industries needing non-metallic vertical pumps or vertical submerged pumps
- Molten salt systems & thermal energy storage loops
- Steel & power plants with submerged circulation & hot oil sump duties
- Molten sulfur, sulfuric acid & other corrosive fluid transfer
- Plants using PP / PVDF / PFA / PTFE vertical pumps for high corrosion resistance
